Ranger RCI 2970N2
(Click on the image for a larger view)
(Scroll down to purchase)

Basics: Dual band 10/12 meter USB/LSB/AM/FM/CW mobile transceiver.
Receive scanning - easily locate activity within the entire band, Programmable frequency - program up to 10 of your most desired frequencies, roger beep, multi function LCD displays frequency S/RF/modulation and SWR meter, frequency select from front panel or microphone push buttons.
Switch functions: NB/ANL, BRT/DIM - 4 levels, roger beep on/off, SWR,
split, scan, program, memory, manual, enter, shift, lock, up, down, mode selection - PA/CW/LSB/USB/AM/FM, VFO
Controls: Volume, squelch, RF power level, mike gain, clarifier, RF gain
Dimensions: W 8" x L 10.5" x T 2.5"
Included Accessories: Stock mike, mike hanger clip, mounting bracket, side mounting screws, power cord, and owners manual
Warranty: 2 year MFG warranty
Condition: New Retail Box (NOT Refurbished)

Detail Information: The new DX models have retained the operating features of its popular predecessors, including programmable repeater offset and capabilities for a CTCSS tone option — great for increasing repeater activity on 10 meters — and receiver scanning for quick search of active frequencies. The units offer three methods of frequency selection, non-volatile memory to store and scan up to ten favorite frequencies, and front panel frequency selector lockout.
In addition, the DX Series offers an impressive array of design and performance improvements:
* An improved receiver: designed for increased sensitivity and image rejections.
* A double FET balanced mixer: for improved receiver inter modulation rejection.
* New pwr supply protection: and temp compensation for improved stability and reliability over wide temperature ranges.
* Surface mount components: for increased resistance to shock and vibration.
* Improved display lighting: for easy reading in a wide range of light conditions.
* Variable power output
Tone Wiring
For complete instructions on wiring a CTCSS tone board into the RCI-2950-2970DX series, please click the corresponding link. TE 32 CTCSS - SS 64 CTCSS - TS 64 CTCSS
Read a review of the RCI-2970DX, from the October, 2001 issue of QST magazine.
Note: Requires Adobe Acrobat to read. QST Review

Turning up the Transmitter's wattage.
Adjusting the modulation for maximum output without distortion.
Modifying the mike amp circuit for more modulation if needed.
Aligning the receiver for optimum signal to noise ratio.
Adjusting the squelch range.

Frequency adjustment to zero tolerance.
Frequency counter display calibration. (If applicable)
Calibrate the Transmit and Receive meter settings.
Perform a complete check of all functions.
Perform a visual of the circuit board for flaws.
